Since switching to the original edrizzi® system in 2015, LiebherrHausgeräte Lienz has not only optimized the cost-effectiveness of its painting process, but has also set new standards in terms of sustainability and ergonomics. The combination of edrizzi® Vario Medium paint mist arrestors and the new NFE03 secondary filter generation impresses with extremely long service life, a simple replacement concept, and optimum separation performance—even with dust-dry premium paints.
Case Summary Liebherr Lienz
- 6-fold increase in service life: Conversion to the edrizzi® system replaced inefficient dry separators with a durable system solution.
- Individually tailored filter technology: 42 paint mist arrestors combined with 42 NFE03 secondary filters – perfect for the dusty Henelit and Mankiewicz paints.
- High production diversity: Painting of up to 50 color variants per year – including special requests from large OEM customers.
- Sustainable filter system: NFE03 secondary filter elements are durable, ergonomically replaceable, and equipped with the sustainable naffi® 40 filter medium.
- Efficiency through innovation: Larger secondary filter surface area (1.02 m²) and storage capacity of up to 8 kg/m² significantly reduce maintenance costs.
- New, glass fiber-free, and recycled naffi® filter mat not only increases service life but also allows filter replacement without protective clothing. In addition, naffi® reduces the CO2 footprint of the system..
Technical data Liebherr Lienz
Location: Liebherr Household Appliances Lienz, Austria
Installation: 2005
System: The Beta Systeme paint booth measures 5 m × 5 m × 4.5 m
edrizzi® system: 42 edrizzi® Vario medium paint mist arrestors, 42 NFE03 secondary filters
Service life: 21 or 28 days, depending on the quantity of paintwork
Surface material: Dust-dry paints in up to 50 color variants: 2K acrylic top coat from Henelit and 2K top coat from Mankiewicz
